Customization of Craft 2 Vessel Brewhouse Beer Brewing Equipment
Beer Production Line
Hubei Yideli Light Industry Technology CO.,LTD. is a professional
beer brewing equipment and service provider, with overseas advanced
technical support, scientific research, production, sales and
service system, we specialize in field of beer brewing equipments'
producing.
The inner of the beer equipment are adopted 304 stainless steel and
mirror-polished. Use polyurethane(80mm) to keep warm. Completely
meet the demanding of PLC and sterilize system.
The cooling jacket can achieve all countries standard, supply
Miller, arch, corrugated plate and so on. Meet all kinds of cooling
technology of coolant and pressure.
The outside scarfskin is according to the customers' requirement.
You can choose stainless steel or red copper, the surface handle
can be mirror polishes, carbon steel, spray finishing and so on, as
you like.
We adopted the international standards of fermentation technology
and diverse methods to control the temperature.
The characteristics of the equipment is: now drink now to brew,
maximum limit is to keep the beer natural freshness and nutrition,
and winemakers can prepare different light beer, wheat beer, red
beer, yellow beer, fruit beer, stout and other fresh, green,
pollution-free beer from the taste of guests, to meet the needs and
tastes of different levels of consumer demand.
Advantage
1) Automatic /semi-automatic operation system ,need one or two
brewer operate
2) with our equipment you can make different kinds beer such as
ale,lager, stout beer and so on.
3) we have different capacity from 50L to 10000L per batch , our
brewery equipment approved Pessure CE, ISO ,TUV certificate
4) have good feedback from our clients
5) Installation/Operation/ Service/ Maintenance Manual: Provided In
English.
Beer brewing equipment are usually independently owned. Such
breweries are
generally characterized by theire empahsis on flavor and brewing
technique. We supply
microbreweries from 500L to 3500L per brew.
| Name | Capacity | Qty | Details |
| Grain Mill | The output is changeable | 1 set | Doulbe roller, adjustable mill degree, stainless
steel,Votage:adjustable |
| Mash System | 200-5000L according to your requirement | 1 set | Material:SUS304,316 or red copper Inner thickness:3mm Outer tank thickness:2mm Surface:Mirror polished Ra≤0.5 or 0.4 Volume: 20% extra headspace Heating method:Electric for small capacity and steam for large
capacity Including valves, spray ball, glass manhole, washing pipeline,PT100
tempreture sensor, Siemens motors. Plasma cutting sieve plate:gap width ≤0.9mm Stainless Steel |
| Hot Liquor Tank | 200-5000L according to your requirement | 1 set | Material:SUS304,316 or red copper Inner thickness:3mm Outer tank thickness:2mm Surface:Mirror polished Ra≤0.5 or 0.4 Volume: 20% extra headspace
|
| Wort Pump | 1-10T/h | 1 set | Simens motor, voltage:adjustable;delivery
lift:24m;inlet:φ38,outlet:φ32 |
| Pipeline | SUS304 | 1 set | Material:SUS304 stainless steel mirror polished |
| Working platform | SUS304 | 1 set | Accroding to your brewery layout SUS304 Stainless Steel |
| Plate heat exchanger | 1-20m^2 | 1 set | Stainless steel SUS304 Double guide cooling process with four stages design pressure:1.25Mpa |
| Fermentation Tank | 200-5000L according to your requirement | 1 set | Material:SUS304,316 or red copper Tank thickness:inner tank:3mm outer tank:2mm Insulation:polyurethane 80mm Preasure:0.2Mpa Top/side manhole(according to your requirement) Accessories:pipeline,spray ball,preasure relief valve,sample
valve,hops port,PT100 sensor |
| Bright(Brite)Beer Tank | 200-5000L according to your requirement | 1 set | Material:SUS304 Tank thickness:inner:3mm outer:2mm |
| Glycol Ice Water Tank | 200-5000L according to your requirement | 1set | material:SUS304 Tank thickness:inner:3mm outer:2mm |
| CIP Cleaning system | adjustable capacity | 1 set | sterilization tank alkali liquor tank |
