1500L Customized Steam Heated Pub Brewing System With 2.00 mm -
3.00 mm Thickness SS
Product Description
1500L Brewhouse Specification
Designing – Individual designing from professional engineer
according to your buisness area. capacity of the brewery is not
limited with space
Convenient – easy for moving to another location without
complicated disassembly and assembly work
Expandability – can be easily upgraded by adding more modules,
spare part with affordable price
Trouble-free installation – onsite engineer installation or remote
controlling installation
Dependability – serial production allows to debug most problems
typical for piece production.
Manual / Automatic operation – customer can choose from cheap
manual or comfort automatic system
1. Brewhouse: two vessels, three vessels, four vessels brewhouse
2. Heating medium: steam heating
3. Insulation material: rock wool. Insulation thickness: 100mm
4. Mash tank; hydrator, mixer, steam heating jacket
5. Lauter tun: rake, agitator, false bottom, hydrator
6. Brewkettle, steam heating jacket, inner steam heating deivce
7. Whirlpool tun: whirlpool entry
Product dvantages :
Appearance clean and generous: The tank is polished by mirror, and
the equipment is bright;
Good insulation effect: The equipment is divided into two kinds of
heat insulation and cold insulation, which is the best to ensure
the temperature of the beer brewing process;
Visualization operation: the equipment is controlled by PLC, and
the fermentation tank is equipped with a glass tube level gauge,
which is convenient for visual operation;
Low energy consumption: environmental protection, energy saving,
low power consumption, saving energy consumption of about 20%;
All stainless steel 304 and electric heating 1500L Brewhouse
Configuration
1 | malt milling system | malt miller machine grist case |
2 | Mash system | Mash tank/lauter tank
Boiling tank/whirlpool tank
Hot water tank
Mash/wort/hot water pump Motors
Wort oxygenation device
Operation platform
Plate heat exchanger |
3 | Fermenting system | Beer fermenters
Bright beer tanks
Yeast adding tank
Accessories, such as sample valve, pressure gauge, safety valve and
so on |
4 | Cooling system | Ice water tank
Refrigerating unit
Ice water pump |
5 | CIP cleaning system | disinfection tank & alkali tank &cleaning pump etc. |
6 | Controller | Control system, we have PLC automatic and semi-automatic, the
elements brand include LG, Siemens and so on. |
7 | Kegging system | kegging system ( keg washer and keg filler machine), the control
system brand is Siemens. |
Beer brewing system’s analysis
item | SLET-0.1 | SLET -0.2 | SLET -0.3 | SLET -0.5 | SLET -1.0 | SLET -2.0 |
Production capacity | 100L/day | 200L/day | 300L/day | 500L/day | 1000L/day | 2000L/day |
floor space | 15m2 | 25m2 | 35m2 | 50m2 | 80m2 | 120m2 |
Total power | 12kw | 12kw | 12kw | 15/36kw | 22/72kw | 31/144kw |
Maximum hourly water consumption | 0.2m3/h | 0.4m3/h | 0.5m3/h | 1.0m3/h | 1.5m3/h | 2.0m3/h |
Total water used | 0.5m3/d | 1.m3/d | 1.5m3/d | 2.5m3/d | 5m3/d | 10m3/d |
Consumption of malt | 20kg | 40kg | 60kg | 100kg | 200kg | 400kg |
Consumption of hops | 60g | 120g | 180g | 300g | 600g | 1.2kg |
Yeast | 100g/1L | 200g/2L | 300g/3L | 500g/5L | 1kg/10L | 2kg/20L |
Maximum steam |
| 0.017t/hour | 0.017t/hour | 0.05t/hour | 0.10t/hour | 0.20t/hour |
