150L Semi-auto Control SUS304 Or 316L Electric Heating Pilot Brewing Equipment
Products Show

Quick Details
1. Products: Pilot Brewing Equipment
2: Capacity: 150L
3: Semi-auto Control
4. Material: Sanitary Stainless Steel SUS304 Or SS316L
5. Function: Beer Brewery
6. Over 10years strong factory
7. Customized service

Feature

Brewhouse system include
Material: SUS 304, Inner 3mm; External 2mm;
Platform with handrails
Inner surface treatment: welds grinded to Ra 0.4µm.CIP cleaning ball
Insulation: Polyurethane-thickness 80 mm.
Equip with : Agitator, Rake knife, sieve plate ects

Fermenting system
Material: SUS 304, Inner 3mm; External 2mm;
Inner surface treatment: welds grinded to Ra 0.4µm (attached cleaning ball).
Insulation: Polyurethane-thickness 80 mm.
Equip with: cone 52-75°resist compression design

Cooling system:
Plate type heat exchanger,
glycol water tank,Refrigerator units

Standard features
1. Custom 2, 3, 4 vessels brewhouse system
2. Material: Food grade stainless steel SUS304 or SUS316 according to your request.
3. Insulation: 75mm rock wool or Ceramic Fiber Blanket
4. Available production capacity from 100L-10,000L or 1-100BBL
5. Round glass manways for malt feeding and observation.
6. Dimple plate steam jacket on the inner shell for heating.
7. Sanitary spray ball for cleaning
8. PT100 sensor for temperature measurement
9. PU liquid level indicator
10. Sanitary butterfly valves for pipeline connecting
11. False bottom gap width≤0.9mm
12. High speed round washing pipe for spent grain washing
13. Side grist exhaust port and dismountable grist slope
14. 4 heavy stainless-steel legs with leveling foot pads
15. Horizontal worm gear reducer mounted on the top seal cap
16. Custom layout for your brewery and area restriction.
17. Sanitary high temperature tolerance centrifugal pump
18. Semi-automatic controlling cabinet
19. Working platform with skid proof stainless steel plate and handrail
20. Steam exhaust pipe

Description
To make the best beer possible, the brew house is the key. On the basis of absorbing European advanced and experienced beer machinery technology, Our Brew house can fulfill various brewing technologies, variable tastes or specific capacities.
10BBL | 20BBL | 30BBL | 40BBL | 50BBL brewhouse sizes are produced standardly, or even larger for customers. The Brew house can be heated with Steam, Gas fired, Electric etc. The system composed of Mash Tun , Lauter Tun, Brew Kettle, Whirlpool Tank etc. The four tanks can be combined together to meet different requirement of brew system.
All the tanks certified stainless steel material for all tanks, with 100% TIG welded joints and seams with sanitary interior polish. All tanks use Tri-clamp connections, are designed for up to 14.7 PSI and tested at 30 PSI. We can custom fabricate any tank to meet your brewery’s space and height restrictions.

Method of Heating Ways:

• Steam: Dimple plate jacket with inlet/outlet fittings for Steam heat transfer;
• Electric: Use electric heaters in jacket to heat the medium in the jacket
• Gas fired: Use gas burner at bottom to heat tank directly;

Application
Our beer brewing equipment include malt crushing system, saccharification system, fermentation system, glycol system, CIP cleaning system, controlling system, packaging system and all complete set of bar selling system, or Micro beer brewery. We could provide customization service, OEM service. Different type of equipment configuration combination could be made as per customer’s requirement.

HUBEI YIDELI LIGHT INDUSTRY TECHNOLOGY CO., LTD. (shortened as YDL INDUSTRY ) is a professional manufacturer of manufacturer and supplier in brewery, chemical & pharmaceutical, food & beverage equipment industry, certified by ISO, CE, TUV, CSA etc. YDL INDUSTRY has over 10 years experiences in design, manufacture, installation and commissioning and try to be the client’s best partner for planning, design, fabrication, management and successful execution for each unique project, satisfy clients with excellent quality and considerate service.

Our main brewery equipment includes as followings:

• Malt Crushing System: Malt mill, Auger
• Mash System: 2/3/4 Vessel Brewhouse
• Fermentation System: Fermenter
• Storage&Maturation System: Brite Tank
• Water System: Hot Liquor Tank, Cold Liquor Tank, Pump
• Cooling System: Glycol Chiller, Heat Exchanger
• Cleaning System: Portable CIP/Integrated CIP
• Filling&Washing System: Keg Filling machine/Keg Washing Machine
• Others: Kegs, Filtration System etc.

We devote all our energy to meet your needs on any budget or production target. Our equipment is combined with good quality, beautiful appearance and durable using.

• We only use quality SS304/SS304L/SS316/SS316L and fine red copper
• Welders who have been welding for more than ten years only
• Key components only use internationally renowned brands
• Such as SIEMENS, ABB, Alfa Laval, we are using the best control instrument
• No matter which part of the weld is welded, we shall protect it with argon of 9999.9% purity

Today’s crafting beer is a blend of both art and process and we love the artistry that today’s brewers are creating. However, we also believe that the application of science, engineering, technology, and automation can give brewers better tools to create even better works of art more efficiently, more economically, more consistently and with greater respect for our environment through unmatched sustainability.

YDL INDUSTRY is dedicated to being the best manufacturer and supplier of brewery equipment, technology, and services to the craft brewing market. Our mission is helping craft breweries “CRAFTING BETTER BEER LIKE GENIUS”
