| Mash Tun | Sanitary Stainless steel 304, Effective volume: 2000L-7000L; |
| Surface brushed, welding line polish sanding light belt; |
| 2''Polyurethank insulation, thickness: 50mm - 100mm; |
| Inner body thickness 3mm, cladding thickness 2mm; |
| Top domed manhole with sight glass, |
| Bottom and side steam jacket; Rotary CIP spray balls, temperature
sense probe, |
| motor with frequency conversion, milled false bottom, side grain
mandoor; |
| Stainless steel legs, with screw assembly to adjust leg height, |
| Complete with associated valves and fittings |
| Lauter tun | Sanitary Stainless steel 304, Effective volume: 2000L-7000L; |
| Surface brushed, welding line polish sanding light belt; |
| 2''Polyurethank insulation, thickness: 50mm - 100mm; |
| Inner body thickness 3mm, cladding thickness 2mm; |
| Top domed manhole with sight glass, |
| Bottom and side steam jacket; Rotary CIP spray balls, temperature
sense probe, |
| motor with frequency conversion, milled false bottom, side grain
mandoor; |
| Stainless steel legs, with screw assembly to adjust leg height, |
| Complete with associated valves and fittings |
| Boil Kettle | Sanitary Stainless steel 304, Effective volume: 2000L-7000L; |
| Surface brushed, welding line polish sanding light belt; |
| Steam jacket; 1 bar pressure release/vaccum valve placed on the
dome |
| for pressure discharging during |
| aggressive sanitation process while the tank is hermetically closed |
| for operation personal safty. |
| Quick installed termo sensor Pt100 connected to multi segments |
| programmable controller. |
| 2''Polyurethank insulation, thickness: 50mm - 100mm; |
| Inner body thickness 3mm, cladding thickness 2mm; |
| Top glass Man-hole door; With sight light; |
| With rotary CIP spray balls; |
| Tangential whirlpool entry; |
| Stainless steel legs, with screw assembly to adjust leg height; |
| Complete with associated valves and fittings. |
| Whirlpool Tank | Sanitary Stainless steel 304, Effective volume: 2000L-7000L; |
| Surface brushed, welding line polish sanding light belt; |
| Steam jacket; 1 bar pressure release/vaccum valve placed on the
dome |
| for pressure discharging during |
| aggressive sanitation process while the tank is hermetically closed |
| for operation personal safty. |
| Quick installed termo sensor Pt100 connected to multi segments |
| programmable controller. |
| 2''Polyurethank insulation, thickness: 50mm - 100mm; |
| Inner body thickness 3mm, cladding thickness 2mm; |
| Top glass Man-hole door; With sight light; |
| With rotary CIP spray balls; |
| Tangential whirlpool entry; |
| Stainless steel legs, with screw assembly to adjust leg height; |
| Complete with associated valves and fittings. |
| Hot water tank | Sanitary Stainless steel 304, effective volume: 2000L-7000L; |
| Surface brushed, welding line polish sanding light belt; |
| 2''Polyurethank insulation, thickness: 50mm - 100mm; inner body
thickness 3mm, |
| cladding thickness 2mm; |
| Top round shape man-hole door; Steam heating coils; |
| Stainless steel legs, with screw assembly to adjust leg height; |
| Outer liquid level pipe; |
| complete with associated valves and fittings |
